Specification
Receiving Frequency
| 791-2690MHz |
Gain
| 791~960MHz = (1.5+/-0.5) 1710~2170MHz = (2.0+/-0.5) 2500~2690MHz = (-0.49~0.07) |
Input impedance
| 50 Ohm |
Dimensions (mm)
| Ø 60 X 216 (H) |
Operating Temperature
| -40 – 85 ℃ |
Operating Humidity
| 0 ~ 95%RH |
V.S.W.R
| ≤3.0 |
Isolation
| >100dB @ 1 MHz ~ 10 GHz |
Cable
| Coaxial Cable 3M |
Connector
| SMA RP Plug |
Storage Temperature
| -40 – 85 ℃ |
