ZN-7100-DE500-G

802.11an 2X2 Dual-Band

  • Supports IEEE 802.11an Standard

  • 29 dBm high powertechnology

  • Data rate up to 600 Mbps

  • CE Certification

  • IP67 Rating

Description

The ZN-7100-DE500-G high integrated, outdoor 802.11ac wireless access point delivers exceptional performance. It supports a wireless transmission rate up to 600Mbps.


With an IP67 rated and lightning protected design, the ZN-7100-DE500-G can operate in harsh weather conditions.


ZN-7100-DE500-G is ideal for Wi-Fi deployment in areas such as campuses, parks, and tourist attractions.



29dBm High Power

Maximum transmit power can be up to 29dBm, bringing superior Wi-Fi signal coverage .


 Flexible installation

Provides various working mode which can be applied flexibly in different scenarios.


Robust Product Design

Encased with IP67-rated design that can withstand harsh environments.






Specification

Standards

IEEE 802.11a/b/g/n/an/ac

Supported Data Rates

- 802.11b: 1/2/5.5/11 Mbps
- 802.11g: 6/9/12/18/24/36/48/54 Mbps
- 802.11n: 300Mbps
- 802.11ac: 300Mbps

Frequency Bands and Operating Channels

Taiwan 2.412 – 2.462 GHz; 11 channels
5.180 – 5.320 GHz; 8 channels
5.500 – 5.720 GHz ; 12 channels
5.745 – 5.825 GHz; 5 channels
US 2.412 – 2.462 GHz; 11 channels
5.180 – 5.320 GHz; 8 channels
5.500 – 5.720 GHz ; 12 channels
5.745 – 5.825 GHz; 5 channels
EU 2.412 – 2.472 GHz; 13 channels
5.180 – 5.320 GHz; 8 channels
5.500 – 5.700 GHz ; 11 channels
China 2.412 – 2.472 GHz; 13 channels
5.745 – 5.825 GHz; 5 channels
Japan 2.412 – 2.472 GHz; 13 channels
5.500 – 5.720 GHz; 12 channels
India 2.412 – 2.472 GHz; 13 channels
5.180 – 5.320 GHz; 8 channels
5.500 – 5.720 GHz ; 12 channels
5.745 – 5.865 GHz; 7 channels
Notice *Operating Channel depends on configured regulatory domain.

Receive Sensitivity

11b: ‐96dBm / 11n: ‐92dBm / 11ac: -82dBm

Interfaces

2 IEEE 802.3u MDI/MDIX 10/100 Base-T Ethernet
1 SFP
1 Reset button
1 Ground terminal
4 N-type connector

IP Rating

IP67

Environmental

Storage Temperature: -40 – 60 ℃
Humidity: 10 – 95%
Operating Temperature: -40– 70 ℃
Humidity: 10– 95% (non-condensing)

Access Method

CAPWAP
SNMP MIB
Telnet
FW upgrade(Web/FTP)
Backup settings(Web/FTP)

Radio Chains

2.4GHz 2x2:2
5GHz 2x2:2

Bandwidth

20 / 40 MHz

Max. Transmit Power

2.4GHz 29dBm
5GHz 26dBm
Notice *The maximum power setting will vary by channel and according to individual country regulations.

Antenna

4 x N-Type Connector

Power

Power Consumption ≤ 26W
Power Input 802.3at (PoE+)

Physical Characteristics

Dimensions 292 (L) × 230 (D) × 67 (H) mm
Weight 2.45kg
Mounting type Pole mount

Operating Mode(s)

TAP: Controller-managed mode
FAP: Standalone AP mode
